18-Stations Roll Reducing Machine
Product introduction
As a manufacturer of heating element equipment with 15 years of production experience, Davinvi's engineering team has been dedicated to developing heating element production equipment.
The 18-Stations Roll Reducing Machine is mainly used to reduce the diameter of the heating tube. It softens the tube by heating and uses 18 set of alloy wheels or steel wheels with precise speed synchronization to perform progressive compression.
As the tube diameter is reduced, it applies a uniform, high static pressure from the outside, thereby effectively compacting the magnesium oxide (MgO) powder in the tube to a very high density. Finally, as the tube diameter is reduced, the density of the magnesium oxide powder increases, which in turn changes the resistance of the heating wire and affects the power and thermal conductivity of the heating tube.
Application
such as rice cooker heating tube, kettle heating tube, water heater heating tube, iron heating tube, hot runner tube, air flyer heating tube, cartridge heater
Metal outer tube (usually stainless steel 304, 316, 316L, Inconel 600, copper, aluminum, etc.) + tightly filled MgO powder inside + central resistance heating wire
Technical Specifications
According to different pipe materials and compression accuracy requirements, we can customize 8-section, 12-section, and 18-section pipe shrinking machines for customers to choose from:
|
Parameter |
Value |
|
Number of stations |
18 stations |
|
Tube materials |
Aluminum, copper, stainless steel (304, 316, etc.) |
|
Tube OD range (input) |
Φ6 – Φ20 mm (custom tooling available) |
|
Tube OD range (output) |
Φ4 – Φ18 mm |
|
Max tube length |
1200 mm (extendable) |
|
Shrinking accuracy |
±0.05 mm |
|
Production rate |
5 – 10 m/min (depending on material & thickness) |
|
Motor power |
12 kW |
|
Power Supply |
380V, 50Hz |
|
Machine weight |
Approx. 2800 kg |
|
Dimensions (L×W×H) |
3500 × 1200 × 1600 mm |
Remark: Values above are for standard configuration; tooling and stations can be customized according to customer requirements.
Product Advantage
1. The 18-station roll reducing machine main body uses an integrated casting molding structure, with small distortion, high precision, and lasting.
2. The speed rate of each pair of axis wheels will increase while the diameter of the pipe is reduced. The details have good linear characteristics and are slightly distorted after pipe shrinkage and elongation, saving materials.
3. When adjusting the roller compression ratio, the roller high center remains unchanged.
4. High geometric precision of the compressed pipe, ovality at<0.05.
5 . Motor with overload protection, when blocked, automatically stops.
6. Speed of pipe shrinking 18m/min. high efficiency.
Initial and final diameter of the tube (including wall thickness).
Tube length: A suitable heating element shrinking machine can be recommended based on the customer's tube length.
Tube material: Stainless steel, carbon steel, copper, aluminum.
Power supply specifications (e.g., single-phase 380V 50Hz).
Recommended roller material: 18-station tube reducing machine with tungsten carbide or steel roller.
Tube applications: Heating elements for air fryers, kettles, electric stoves, etc.
Frequently Asked Questions (FAQ)
Q: Is the 18-station machine more expensive than the one with fewer stations?
A: Yes, but the significantly reduced scrap rate and higher product yield usually allow you to recoup the extra cost within 6-12 months.
Q: Can it process stainless steel tubes?
A: Yes. We recommend using alloy wheels for processing stainless steel heating elements. Alloy wheels are more wear-resistant and extend the equipment's lifespan.
Q: How long does it take to change the mold?
A: Due to the use of 18 sets of progressive tube shrinking wheels, the diameter reduction values are different for each set. It is not recommended for inexperienced engineers to change the mold themselves. Skilled operators can complete mold changes and equipment debugging in approximately 5-6 hours.
Q: Can this machine be integrated into an automated production line?
A: Yes. This machine can automatically feed materials via a feeder, eliminating the need for manual feeding and achieving automatic loading and unloading of heating elements.
What about the Davinci Machine?
Davinci mainly specializes in: Cartridge heaters, Tubular heaters, band heaters, ceramic heaters, silicone rubber heaters, thermocouples, and other industrial heating elements; temperature measuring components and production equipment, accessories, and raw materials.
Established in 2015, Foshan Davinci is a manufacturer of electric heating pipe equipment in Guangdong. It has been focusing on the research and development, production, and sales of electric heating pipe production equipment and electric heating elements, as well as a one-stop service system.
Engineering Team
1. Professional: With 25 years of experience in small home appliance and cookware production lines
2. There are 7 after-sales service points around the world, and our engineers can go to your factory for equipment commissioning and installation
The tube rolling machine can be used together with the GV-014 Feeding machine and can be equipped with a tube marking device.
Hot Tags: 18-stations roll reducing machine, China 18-stations roll reducing machine manufacturers, suppliers, 12 Stations Pipe Shrinking Machine, 12 StationsCopper Tube Shrinking Machine
Package & Shipment
1. For LCL shipment, we use export wooden boxes or wooden frames for packaging
2. For FCL shipment, we will directly fix the container with Iron coil wire
3. Precision measurement equipment size. Our purpose is to keep the machine safe during delivery. Also can satisfy your needs, about inspection & quarantine, CIQ, fumigation, etc
