Automatic feeder for heater shrinking machine
Product Overview
In the production of heating elements, the heating elements are usually fed manually to the heater shrinking machine for shrinking. An automatic feeder is an automation solution that improves the efficiency and accuracy of the feeding operation during the production process.
It adopts a chain-type feeder, which is durable, and uses a motor for feeding and loading, with adjustable speed, making the operation simple and quick.
Technical parameter
|
Power Supply |
Single phase 220V\50Hz\100W |
|
Gas Source |
0.5~0.8MPa |
|
Effectiveness |
3000~15000 pcs/8 hours |
|
Diameter |
1000x850x1200mm(1 meter model) 1500x850x1200mm(1.5 meter model) |
|
Weight |
160kg(1 meter model) 250kg(1.5 meter model) |
Key Features
1. Fully automatic operation: Simply place the heating element on the feeding table and start the machine. The Automatic feeder for heater shrinking machine will automatically deliver the heating element into the tube shrinking machine. Operation is simple and convenient.
2. Flexible heating element size processing: Suitable for heating elements from 0.5 meters to approximately 4 meters in length. For heating elements longer than 5 meters, manual feeding is recommended.
3. Optional high-voltage testing function: If included, it will automatically sort heating elements that fail the high-voltage test, significantly improving production efficiency and quality.
Product Highlights
The main buttons on the feeder function as follows:
1. Power Switch: After the Automatic feeder for heater shrinking machine is connected to the circuit, turn this switch to the right to start the equipment.
2. Chain Start: Turns on the chain motor, allowing the chain to rotate and feed the heating element into the tube shrinking machine.
3. Automatic Feed: Turns on the feed motor, feeding the heating element from the hopper into the chain.
4. Frequency Converter: Adjusts the frequency of the feed motor, controlling the motor's rotation speed and thus the feeding speed.
5. Speed Regulator: Adjusts the speed of the chain motor, controlling the chain speed. (The switch on the panel must be turned on before adjustments can be made.)
Precautions for use
1. The installation environment of the automatic feeder for heater shrinking machine must be free of moisture, corrosive gases, and flammable gases; the equipment must not be used near flammable materials.
2. The machine must be placed on a level surface, and the production area must be kept clean.
3. The installation and wiring of the machine must be completed by qualified electricians and mechanics.
4. The power supply used by this equipment is: three-phase four-wire (ensure grounding) 380V, 50Hz, 0.6KW. Before starting the machine, ensure that the input power voltage is correct; otherwise, it may cause equipment damage and personal injury.
5. The normal operating pressure of the equipment is within the range of 0.5MPa~0.8MPa.
6. Repeated switching on and off is prohibited. Each switch on and off should be spaced at least 10 seconds apart.
7. This equipment has mechanical conveying parts; it is strictly forbidden to put any part of the body into them to avoid personal injury.
8. Before production, adjust the position of the heating element. During production, it is strictly forbidden to adjust any parts; adjustments can only be made after the equipment is turned off.
9. When performing mechanical adjustments and maintenance on the equipment, the power should be turned off to avoid personal injury.
Frequently Asked Questions
Q1: What is your delivery time?
A: Typically, 7 days for in-stock machines or 25 days for made-to-order production.
Q2: Can you provide all machine parameters?
A: Absolutely, we are happy to supply comprehensive information about our machines.
Q3: What about after-sales service?
A: We offer on-site installation and training by our engineers.
Elevate your production capabilities with our Heating Tube Feeding Machine. For detailed specifications or to discuss your requirements, please contact us!
