Single-Column Mgo Powder Filling Machine
Products Description
Single-Column Mgo Powder Filling Machine is an efficient automated equipment professionally designed for powder filling. The machine adopts advanced technology and reliable design and is designed to meet the precise metering and rapid filling needs of magnesium powder, magnesium oxide, and other powder materials in industrial production.
Specification of Widened Powder Filling Machine
| Model | Pipe Length(mm) |
Oscillation Mode |
Fixed Adjustment |
Size(L*W*H)mm | Weight(kg) |
| JD0201W-05 | 155 ~ 500 | Motor | Selectable | 1500X1100X2800 | 740 |
| JD0201W-10 | 155 〜1000 | Motor | Selectable | 1500X1100X3300 | 760 |
| JD0201W-15 | 200 ~ 1500 | Motor | Selectable | 1500X1100X4400 | 800 |
| JD0201W-20 | 800 〜2000 | Motor | Selectable | 1500X1100X5500 | 850 |
Scope of application
The Single-Column Mgo Powder Filling Machine is suitable for the heating tubes of various appliances, including Electric Rice Cookers, Electric Kettles, Irons, and more.
Main feature
1. Precise Measuring and Filling: The Single-Column Mgo Powder Filling Machine is equipped with a high-precision metering system, which can accurately measure and fill the required amount of powder, ensuring the consistency of the weight and quantity of the product.
2. Efficient production: This equipment adopts an advanced automated control system, which can achieve fast and continuous production operations, greatly improving production efficiency.
3. Flexible to adapt to different needs: Single-Column Mgo Powder Filling Machine can be customized according to customers' specific requirements, including different filling capacities, different packaging specifications, etc., to meet the needs of different production scenarios.
4. Stable and reliable: The equipment is made of high-quality materials and precision processing technology. It has excellent stability and durability and can operate stably for a long time without failure.
5. Easy to operate: The equipment adopts a humanized design and the operation interface is simple and easy to understand. Operators can easily master the operation skills without complicated training.
6. One machine for multiple uses: This equipment can replace the corresponding mold according to different pipe diameters, saving equipment costs and space.
Important Part
1. Filling Hopper - This is the part of the machine where the filler material is stored. It is equipped with a level indicator and a conveyor belt that carries the material to the filling nozzle.
2. Filling Nozzle- This is the part of the machine that inserts the filler material into the heating tubes. It is designed to be accurate and uniform, ensuring consistency in the final product.
3. Control Panel- This is the part of the Single-Column Mgo Powder Filling Machine where the operator can control and adjust the various settings of the machine, such as the speed of the conveyor belt and the amount of filler material to be inserted into each heating tube.
4. Heating Tube - This is the part of the electric rice cooker where the heating takes place. It is an important component of the Single-Column Mgo Powder Filling Machine, and the accurate filling of the filler material ensures that the heating is efficient and reliable.
Information required for placing an order:
1. Heating tube material, length, wall thickness, and diameter
2. Number of different tube diameters required for one machine
3. Heating tube production efficiency requirements
4. Language requirements for power supply and PLC control panel
There are other types of powder filling machines: double columns powder filling machine,four columns powder filling machine, widened column powder filling machine
service and support
Davinci provides a full range of pre-sales consultation, customized design, equipment installation and commissioning, after-sales maintenance and other services to ensure that customers get the best experience and value during the purchase and use process.
If you have any questions or need further information about the Single-Column Mgo Powder Filling Machine or other products, please feel free to contact us and we will be happy to serve you!
